Masterscreed MS430
MS430 – Our First Robotic Automated Screed
Lightweight and suitable to be used on upper/lower concrete floors, drive on steel bars, steel mesh, and insulation.
THE MS430 OUR SMALL RANGE ROBOTIC SCREED WITH PLOUGH, AUGER AND VIBRATOR SCREED HEAD
Our most versatile and nimble fully automated robotic screed, suitable for many applications and easy to operate via radio control, fully automated via one function. Lightweight and suitable to be used on upper/lower concrete floors, drive on steel bars, steel mesh, and insulation.
Fitted with the trusted LEVmaster Ultimate system, it allows the operator full control to customise the machine to suit the concrete slump, fully adjustable with live onboard diagnostics.
MS430 Specifications:
- Drive : 2WD Drive (4WD optional)
- Wheels: 2 x 21’ and 2 x 16” MX with non puncturing inner tube
- Pressure Washer: 2000psi
- 3D ready, GPS & sonar tracer (optional)
- Steering System: Two Wheels Hydraulic (rear)
- Weight: 650kg
- Elevation Control: LEVmaster(TM) MK5 advanced operating system
- Machine Operation Control: Wireless Remote
- Laser Receivers: Trimble® 2 x LR410
- Screed Width: 9’ 10” (3.0m) with auger and vibrtor
- Screed Head: New 2 in 1 versatile head with auger and double beam
